The NanoOne 1000 is a 2-photon polymerization (2PP) 3D printing system from UpNano featuring a 1000 mW femtosecond fiber laser with a 90 fs pulse length — the most powerful femtosecond laser in its class. It goes beyond traditional 2PP applications by enabling the creation of mesoscale structures and printing with demanding, exotic resins, delivering intricate nanoscale details.
The NanoOne 1000 unlocks endless possibilities with the most powerful femtosecond laser in its class. This advanced technology goes beyond traditional 2PP applications, enabling the creation of mesoscale structures and the use of exotic resins. With the NanoOne 1000, you can craft intricate details and push the boundaries of innovation in 3D printing. Experience the future of precision and creativity with the NanoOne 1000.
| System type | Desktop multiphoton laser lithography system |
|---|---|
| Printing process | Layer-by-layer 2-photon polymerization |
| Light source | Femtosecond fiber laser |
| Laser wavelength | 780 nm |
| Output power of femtosecond laser | 1000 mW |
| Scanner | Galvanometer scanner |
| Stage | Long-range piezo stage |
| Maximum travel range | Up to 120 x 100 x 49 mm |
| Stage address grid | 10 nm |
| System dimensions | Benchtop system 58.5 x 71.0 x 65.0 cm³ |
| Total weight | 124 kg |
